10380062100

Series	IM
Size	M1
Nr. Module Spaces	1
Nr. Contacts	6
Gender	Male
Connection 1 Type	Crimp
Rated Current(IEC)	16A
Rated Voltage(IEC)	500V
Rated Impulse Voltage	6kV
Conductor Cross-section	0.14-4mm²
Contact Resistance	<1mΩ
Insulation Stripping Length	Please refer to crimp contact data
Overvoltage Category	III
Pollution Degree	3
Material(insert)	Polycarbonate (PC)
Colour(insert)	Pebble Grey (RAL 7032)
Material Flammability Class Acc. To UL 94	V-0
Limiting temperature	-40…+125°C
Insulation resistance	>1010Ω
Insulation Material Group	IIIa
Mating Cycles	≥500
Material(Contact)	Copper alloy
Surface(Contact)	Silver
ContactSeries	CE
CE	Yes
RoHS	Compliant with exemption
China RoHS	Compliant with exemption
Country of Origin	China
European Customs tariff number	85366990

Krimpovací napájací modul pre 6 kontaktov - vidlica/samec. Modul je určený pre 16A/500V.
Krimpovacie kontakty sa objednávajú zvlášť - (nájdete ich nižšie v súvisiacich produktoch)
Modul zaberá jedno miesto v modulárnom rámiku.
Kompatibilita s výrobcami Harting a Ilme.
