• 10300101100

10300101100

Názov produktu: IA-010-M

Dostupnosť: Skladom 20KS
KS Cena
1 9.09€ / 10.91€ s DPH
KS

Dokumentácia

Icon pdf

Technické informácie

Series IA
Size A10
Nr. Contacts 10+PE
Gender Male
Connection 1 Type Screw - withOut Wire Protector
Rated Current(IEC) 16A
Rated Voltage(IEC) 250V
Rated Impulse Voltage 4kV
Conductor Cross-section 0.75-2.5mm²
Contact Resistance <1mΩ
Insulation Stripping Length 7.5mm
Contact Clamping Screw Size M3
Overvoltage Category III
Pollution Degree 3
Material(insert) Polycarbonate (PC)
Colour(insert) Pebble Grey (RAL 7032)
Material Flammability Class Acc. To UL 94 V-0
Limiting temperature -40…+125°C
Insulation resistance >1010
Insulation Material Group IIIa
Mating Cycles ≥500
Material(Contact) Copper alloy
Surface(Contact) Silver
CE Yes
RoHS Compliant with exemption
China RoHS Compliant with exemption
Country of Origin China
European Customs tariff number 85366990

Popis

Size: A10,Nr. Contacts: 10+PE,Screw - withOut Wire Protector,Rated Current: 16A,Rated Voltage: 250V,0.75-2.5mm_
