10010030011
Názov produktu: HA03-TE/S-DB-M20
Dostupnosť: Dodací termín na vyžiadanie
| KS | Cena |
|---|---|
| 1 | 4.72€ / 5.66€ s DPH |
KS
Dokumentácia
Technické informácie
| Housing Series | Standard |
| Size | A03 |
| Housing Type | Hood |
| Housing Options | with glued seal |
| Number of Cable Entries | 1 |
| Cable Entry Position | Top entry |
| Type of Cable Entry | Threaded Hole |
| Thread Type & Size | M20 |
| Locking Type | Single Locking |
| Limiting Temperature | -40…+125°C |
| IP Protection | IP65 |
| NEMA Protection Rating | 4X, 12 |
| Housing Material | Zinc die-cast |
| Housing Surface | Epoxy Powder coated |
| Housing Colour | Dust Grey (RAL 7037) |
| Material(Locking) | Zinc die-cast |
| Material(Seal) | NBR |
| CE | Yes |
| RoHS | Compliant with exemption |
| China RoHS | Compliant with exemption |
| Country of Origin | ChinaEuropean customs tariff number |
